2013 Ker 46

Specifications

Equipment & Extras

Rig

Sloop

Keel

Fin Keel

Name

Daguet 3

Class

Performance Sail

Berths

8

Layout

Aft Cockpit

IRC TCC

1.287 (2024)

ISO OSR

CAT. 1

Engine HP

38 hp

Boat EPIRB

2

Life Rafts

2 x Ocean Safety light carbon

Ancasta Ref

47643

Engine Make

NANI

Engine Year

2023 (new)

Pit Winches

1 x Harken 50.2

Construction

McConaghy Boats

Engine Model

N4.38

Life Jackets

13 x Spinlock deckvest equipped with AIS automatic Ocean safety

Engine Battery

1 x Lithium

ISO Structural

CAT. A

Personal EPIRB

13

House Batteries

2 x Lithium

Naval Architect

Ker Yacht Design

Primary Winches

2 x Harken 65.3 STR UD (driven)

Backstay Winches

2 x Harken 50.2ST

Displacement IRC

6278 Kg

Fuel Tank Capacity

52L

Main Sheet Winches

2 x Harken 65.3 STR

Hull & Deck Construction

Full carbon construction with vacuum consolidated carbon/foam sandwich throughout, with unidirectional fibre reinforcement.

• Harken MX pedestal mounted aft of traveller
• ‘Pro-Trim’ traveller system
• Spinlock clutches
• Custom organizers
• Composite aerofoil stanchions, pushpit & pulpit
• Stainless steel 1/19 wire lifelines
• 8 x clear dinghy hatches in cockpit sides for rope stowage
• Sliding fore hatch with inflatable seal
• String drop system lead to main winch
• McConaghy carbon fibre winch handle pockets
• Foredeck toe rails to ORC standard
• Retractable propulsion unit with fixed five blade propeller
• Spinlock flush throttle control
• Category OSR2 full equipped
• Auto pilot mounting bracket
• Prisms above head and nav station for extra light
• Mainsheet trimmer console and purchase system for main cunningham, outhaul, jib tack & traveller
• Electric auto/manual bilge pump system (6 Additional Bilge Pumps)
• Soft padeyes instead of folding pad eyes where ever possible
• Wheel steering package (2 wheels)
• Adjustable helm platforms
• Foot button controls for pedestal
• 3 x Unreelers for spinnaker sheet and spinnaker halyard tidy up
• Foredeck hatch has pneumatic seal operational from mast bracket and below deck
• Custom carbon roller at foredeck hatch for spinnaker string drops
• Internal bocks for spinnaker string drop system
• Mast gate customized to rectangular shape to allow shims
• Adjustable mast step with built in mast jack, pump mounted on bulkhead in the head
• Full boat cover (deck and cockpit)
• Boom and mast cover
• Cockpit work covers
• Spare Bowsprit
• Spare Rudder
• Spare Wheel x2
• Spare Gorilla head foil
• Spare Pushpit and pullpit and stanchions
• A lot of spare winch parts
• Spare Inflatable hatch seal
• Spare EC6 runner x2
• Spare Full mast head unit
• Boat cradle high and low positions (storage and shipping)
• Keel cradle
• Red/white cabin lighting in saloon, galley, head and navigation areas
• 12-volt DC switch panel battery isolator/selection switch
• Navigation lights pulpit, pushpit mounted
• Offshore door fitted for water tightness (2019)
• Mast repainted Alw Grip Black (2021)
• John buoy and Dan buoy fitted on central pushpit (2021)
• Customized kitchen/galley area (new 2021)
• New rudder designed by KER and made by HEOLE Composite (2021)
• New Bulb (2021 machined by Fonderie LEMER, 2021)
• New rudder bearing JP3 (2022)
• New Mast jack pump (2022)
• New bowsprit made by HEOLE Composite (2023)
• Load cell on spinnaker tack by Diverse (2023)
• Non skid foam SEADEK inside boat (2023)
• Fuel tank and pipes (2023)
• Main computer (2021)
• Tablet (2023)
• Starlink antenna (2024)
• All V Blocks from Harken (Main sail, runners, Sheets)
• Running rigging (replaced each year)
• All sails from North Sails, using a mix of Australian and French sail lofts
• Mainsails: MN-1 June 20 (Offshore), MN- October 21 (Delivery), MN-2 March 22 (Offshore), MN-3 June 24 (Inshore)
• JIB #1: J1-1 June 20, J1-2 March 22, J1-3 June 24
• JIB #2: J2-1 June 20, J2-2 March 22, J2-3 June 24
• JIB #3: J3-1 February 21, J3-2 October 23
• JIB #4: J4-1 February 21
• JIBTOP: FJTP-1 January 23
• GSS: GSS-2 March 22, GSS-3 January 24
• Downwind A #1: A1-1 June 20, A1-2 September 22, A1.5-1 October 22, A1.5-2 January 24
• Downwind A #2: A2-2 August 20, A2-3 June 24, A2-4 January 24
• Downwind A #4: A4-1 February 21, A4-2 August 22
• Downwind A #5: A5-1 February 21
• CODE: C0-1 June 20, C0-2 January 23
• WS: WS-1 October 21, J05-1 October 23
• SS Spinnaker Staysail: 2016
